The production line is a semi-automatic production line with a total of 20 work stations to complete the assembly, inspection and packaging of the disk motor. It has the function of anti-dumbness, has the ability of hand automatic switching, and has the ability of data tracing.
The whole line beats 8 minutes each.
Loading of stator shell
The casing stator is tightened
Spring pad installation, right shell coated with glue
Rotor premounting
Magnetic steel assembly
Dynamic balance test
Bearing pressing
Fixed rotor assembly
Seal coating
Cover mounting
Air tightness test
Insulation withstand voltage test
Rotor assembly
Harness assembly
High voltage wire cover plate, wiring harness assembly
Oil seal assembly
Air tightness test of the whole machine
EOL test
Laser marking
pack
